Powerful 128CH wireless IP camera standalone recorder 4K NVR, XONZ intelligent H265 4K NVR by Linux operating system

FOB Reference Price:Get Latest Price
$1,566.20 - $1,660.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
Xonz
Model Number:
XZ-N924-128E
Recording:
128CH 4K
Playback:
4CH 4K-5mp, or 9CH 4mp-3mp, or 16CH 2mp 1-30fps
Standard:
H.264+
Video output:
HDMI and GVA
SATA:
24SATA Max 6TB/each
Alarm:
16In 8Out
Power Supply:
ATX 100-240V 400W
Warranty:
2 years
Protocol:
Support Onvif protocol
Key word:
4K NVR
Supply Ability
Supply Ability:
60000 Unit/Units per Month 2000pcs per day
Packaging & Delivery
Packaging Details
Xonz Brand or Neutral packing
Port
Shenzhen /Hongkong

Powerful 128CH wireless IP camera standalone recorder 4K NVR, XONZ intelligent H264+ 4K NVR by Linux operating system



Product Description

Features:

• Support 128ch full 4k video real-time access, 4U NVR, 24SATA ports.

• Support H.264+/H.264 stream, embedded Linux operating system.

• Support video playback, remote monitoring and backup.

• Support preview and playback with 12 times electronic amplification.

Standard ONVIF, RTSP, GB28181 protocol.

• Support DDNS, EMAIL, UPNP, NTP, etc.

• Support Web, mobile monitoring, PC client,CMS software.

Support TUTK P2P.

• Double 100/1000M ethernet ports, double IP range.

• Support RAID0, RAID1, RAID5, RAID6 and RAID10.

• Support channel grouping, preview cycle.

• Support NVRsmart analysis (Target count, Item detection, Area detection, Virtual cordon, Scene transformation).

• Support 16ch 1080P  video synchronous playback and multi channel synchronous playback.

• Support dual password authentication.



 System

 Operating System

 Embedded Linux operating system

 Video

 Network video input

 128ch 4K/5MP/3MP/1080p/960p/720p input

 Network video output

2*VGA/2* HDMI, 3840×2160@30HZ,1920×1080@60HZ,1280×1024@60HZ

 Video bit rate

 16-8000Kbps

 Image preview

 1/4/6/8/9/16/25/36/64 channel

 Video compression

H.265/H.264/MJPEG

 Capture mode

 Schedule/Manual, JPEG format

 Audio



1ch audio input and 1ch output

 Audio compression

 G.711A

 Storage

 HDD port

 24 SATA ports, 1 E-SATA

 Raid mode

Raid0, Raid1, Raid5, Raid6, Raid10

 Capacity

 Support 6TB HDD

 Alarm

 Motion detection

Support image set to 396 (22*18) detection areas, multistage sensitivity

 Smart detection

 Motion detection, video miss, video occlusion, occlusion alarm

 Alarm

16ch input,8ch output

 Network management

 Network protocol

TCP/IP,HTTP,DDNS,SMTP(SSL),DHCP,PPPOE,UPNP,NTP

 Compliance protocol

 ONVIF, RTSP, GB28181

 Remote application

 WEB(IE, Chrome, Firefox, Safiri), IOS, Android Mobile monitor

 Smart analysis

Target count, Item detection, Area detection, Virtual cordon, Scene transformation

 Others

 Dual password authentication

 Video management

 Record mode

 Manual/Schedule record, Motion alarm record, Motion alarm Snap, link down record

 Resolution

128ch 4K/5MP/3MP/1080p/960p/720p

 Broadband access

 640Mbps

 Record frame rate

 1-30fps

 Video query

Time, Date, Event, Channel, Exact Search (accurate to second)

 Record storage path

 Local, Network, NAS, IPSAN

 Playback&Backup

 Playback mode

Regular playback, instant replay, event playback, external file playback

 Playback capability

 4ch 4K/5MP

 9ch  3MP

 16ch 1080p/960p/720p

 Playback operations

Play, Stop, Rewind, Next File, Previous File, Next Camera, Previous Camera, Fast play, Slow play, Single frame, Backup, Screenshot, Full screen selection

 Backup mode

 Removable HDD, USB flash disk, Network backup

 External ports

 Network port

 2 RJ45 Ports (100M/1000M Ethernet port )

 USB port

2pcs 2.0 USB port, 1pcs 3.0 USB port

 RS485 port

Support

 Audio port

1pcs input, 2pcs output

 General

 Power supply

AC100~240V,47Hz~63Hz

 Power consumption

≤ 50W (Without HDD)

 Storage condition

 -10°C ~ 55°C / 10%-90% RH

 Dimensions

 W431.5mm×D600mm×H177.5mm

 Weight

23KG





Pictures






Company Information

Shenzhen XONZ Technology Co.,Ltd. located in Shenzhen China,is a High-tech Enterprise which is engaged in designing,manufacturing and selling all kinds of HD IP cameras,NVRs and Car series that owe 3000 square meters manufacturing area.We have experienced R&D team and advance R&D test equipment,and develop some project with a number of University Institute in China.



Product involved in 1.0 / 1.3 / 2.0 / 3.0/4.0 / 5.0 megapixel IP cameras,   WIFI IP cameras, smart home security cameras, Starlightseries cameras ; 360 degree panoramic cameras,   PTZ series IP cameras, high speed dome IP cameras,  4CH / 8CH / 9CH / 16CH / 32CH/64CH/128CH NVRs,  can offer OEM / ODM service. Xonz products have been passed FCC,CCC , CE , RoHs, certification,the product sells all around Europe,Northern America, Southeast Asia and Latin America.
